Standard Package Hot Dip Dx51d Galvanized Color Coated Steel Coil Ral 5020 Pre Painted Galvanized Steel Coil for 100-1250mm Width
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | Zhongsheng |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Ton |
|---|---|
| Price: | $600.00/tons 1-24 tons |
|
Detail Information |
|||
| Application: | Making Pipes, Cutting Sheets, Making Small Tools, Making Corrugated Sheets, Making Container, Making Fences | Type: | Steel Coil |
|---|---|---|---|
| Thickness: | 0.12-3.0mm | Standard: | ASTM |
| Width: | 100-1250mm | Length: | Coil |
| Certificate: | API, Ce, Rohs, SNI, BIS, SASO, PVOC, SONCAP, SABS, Sirm, Tisi, KS, JIS, GS, ISO9001 | Grade: | DX51D+Z/SGCC/DC01+Z/DC51D+Z Etc |
| Coating: | Z121-Z180 | Tolerance: | ±1% |
| Processing Service: | Welding, Punching, Cutting, Bending, Decoiling | RAL Color: | Red, Blue, Green, White, Grey, Ects. |
| Hardness: | Full Hard, Medium Hard(HRB60-85) | Delivery Time: | Within 7 Days |
| Product Name: | PPGL Coil | Surface: | PE Coated |
| Color: | Red, Blue, Green, White, Grey, Ects. | Keyword: | PPGI Coil Prepainted Steel Coil |
| Shape: | Coil Roll | Material: | ASTM/AISI/SGCC/CGCC/TDC51DZM/TDC52DTS350GD/TS550GD/DX51D+Z Q195-q345 |
| Packages: | Standard Package | Coil Weight: | 3-8 Tons |
| MOQ: | 1 Tons | ||
Product Description
Product Description
HIGH PERFORMANCE
Excellent corrosion resistance 8 high heat resistance & adequate zinc layer
HIGH QUALITY
Best raw materials for production advanced technologiesand thorough inspection system
CUSTOMIZABLE SURFACE
perfect painting& beautiful appearance customize your different needs
PPGI/PPGL | ||
Standard | JIS G3302, JIS G3313 | |
ASTM A653 | ||
GB/T2518-88, GB11253-9, BS, etc. | ||
BASE MATERIAL | HDGI HDGL | |
Thickness | 0.12-3.0mm | |
Width | 100mm-1250mm or as you require | |
Zinc Coating | Z20-Z275,AZ30-AZ150 | |
Painting Thickness | Top side: 10-20microns | |
Primer: 5~7microns | ||
Back side: 5~7microns | ||
Color | RAL Color | |
Package weight | 2 -6 ton per coil | |
Inner Diameter | 508mm, 610mm | |
Surface Production | PE, PVDF, SMP, HDP etc | |
Packing | Each bare coil to be securely tied with two bands through the eye of coil (or not) and one circumferential. | |
The contact points of these bands on the coil edge to be protect with edge protectors. | ||
Coil to be properly wrapped with water proof /resistant paper, it then to be properly and completely metal wrapped. | ||
Coating Type
Polyester (PE): Good adhesion, rich colors, wide range in formability and outdoor durability, medium chemical resistance, and low cost.
Silicon modified polyester(SMP): Good abrasion resistance and heat resistance, as well as good external durability and chalking resistance, gloss retention, general flexibility, and medium cost.
High Durability Polyester(HDP): Excellent color retention and anti-ultraviolet performance, excellent outdoor durability and anti-pulverization, good paint film adhesion, rich color, excellent cost performance.
Polyvinylidene Fluoride(PVDF): Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, excellent solvent resistance, good moldability, stain resistance, limited color, and high cost.
Polyester (PE): Good adhesion, rich colors, wide range in formability and outdoor durability, medium chemical resistance, and low cost.
Silicon modified polyester(SMP): Good abrasion resistance and heat resistance, as well as good external durability and chalking resistance, gloss retention, general flexibility, and medium cost.
High Durability Polyester(HDP): Excellent color retention and anti-ultraviolet performance, excellent outdoor durability and anti-pulverization, good paint film adhesion, rich color, excellent cost performance.
Polyvinylidene Fluoride(PVDF): Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, excellent solvent resistance, good moldability, stain resistance, limited color, and high cost.
Packing & Delivery
Exported sea worthy packing: 3 layers of packing. Inside is craft paper, middle is waterproof plastic film and outside GI steel sheet to be covered by steel strips with lock.
Company Profile
Shandong Zhongsheng Materials Co., Ltd. is a comprehensive, modern and high-quality enterprise integrating steel production, processing and sales. Located in the north near the port city: Jinan. Nearby Tianjin, Qingdao, Shanghai ports, low transportation cost, steel price concessions. Since its establishment, the company has developed rapidly. It has established long-term and stable cooperative relations with Shandong Iron and steel, Rizhao Iron and steel, Shanxi Taiyuan Iron and steel, Shanghai Baosteel, Xiwang special steel and other domestic steel mills.
Customer high praise
FAQ
Q: Are you trading company or manufacturer ?
A: We are professional manufacturer. Our company have been in steel business for more than ten years. We are internationally experienced, and we can provide variety of steel products with high quality to our client.
A: We are professional manufacturer. Our company have been in steel business for more than ten years. We are internationally experienced, and we can provide variety of steel products with high quality to our client.
Q: How long is your delivery time?
A: We have a large inventory. If the product you want is of standard specifications, we will ship it within 3 days. If it is of
non-standard specifications, the production cycle will be negotiated between the two parties according to the specifications and quantity of the product.
Q: Do you provide samples ? Is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance, balance before shipment.
A: We have a large inventory. If the product you want is of standard specifications, we will ship it within 3 days. If it is of
non-standard specifications, the production cycle will be negotiated between the two parties according to the specifications and quantity of the product.
Q: Do you provide samples ? Is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance, balance before shipment.
