700x300 H Steel Beam HEA 450 H Beam 12m 294*200 Steel H Beam with EN Standard and Flange Thickness 4.5-35mm at Cheaper
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | ZHONGSHENG |
| Model Number: | Q235B Q345B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Ton |
|---|---|
| Price: | $582.00/tons 1-9 tons |
| Packaging Details: | Standard Seaworth Packing<br>294*200 steel h beam |
| Supply Ability: | 25000 Ton/Tons per Month hea 450 h beam |
|
Detail Information |
|||
| Grade: | Q235 | Technique: | Hot Rolled |
|---|---|---|---|
| Thickness: | 4.5-35mm | Application: | Industry, Construction |
| Length: | 5.8m,6m,9m,11.8m,12m Or As Your Requirement | Standard: | EN,Astm,JIS, GB,DIN,etc. |
| Flange Width: | 100-1000mm, 100-1000mm | Flange Thickness: | 4.5-35mm |
| Web Width: | 100-450mm | Web Thickness: | 4.5-70mm |
| Tolerance: | ±1% | Processing Service: | Bending, Welding, Decoiling, Punching, Cutting |
| Alloy Or Not: | Non-Alloy | Invoicing: | By Actual Weight |
| Delivery Time: | Within 7 Days | Material: | Q195,Q215,Q235,Q345,16Mn,etc. |
| Technical: | Hot Rolled Molding And High Frequency Welded | Type: | Carbon And GI |
| Keyword: | H/I /Beam | Usage: | Industry, Construction, Steel Structure |
| MOQ: | 1 Ton | Payment Terms: | L/C T/T (30% Deposit),etc |
| Packing: | Follow Customer's Request | Port: | Qingdao |
Product Description
Product name | H steel beam / I steel beam | ||||||
Grade | Q195,Q215,Q235,Q345,16Mn,ASTMA36,ASTMA572,SS400,SS490,A36,S235JR,S355JR,ST37,ST52,etc | ||||||
Standard | AISI, ASTM, BS, DIN, GB, JIS, EN,etc | ||||||
Flange Thickness | 4.5-35mm | ||||||
Flange Width | 100-1000mm | ||||||
Web Thickness | 4.5-70mm | ||||||
Web Width | 100-450mm | ||||||
Length | 5.8m,6m,9m,11.8m,12m or as your requirement | ||||||
Surface | Perforated/galvanized/black/Paint | ||||||
Bright, Polished, Turn smooth(Peeled),Brush, Mill,Pickled | |||||||
Technique | Hot-rolled and High frequency welded | ||||||
Application | 1.Industrial structure of the steel structure bearing bracket 2.Underground engineering steel pile and retaining structure 3.Petrochemical and electric power and other industrial equipment structure 4.Large span steel bridge components 5.Ships, machinery manufacturing frame structure 6.The train, automobile, tractor beam bracket 7.Port of conveyor belt, high speed damper bracket | ||||||
Packing | In bulk or container,Standard seaworthy packing or as your required | ||||||
Payment Term | TT/LC/ After Copy of the BL | ||||||
Delivery Time | Within 7days | ||||||
H - beam steel is a new economic construction steel.
H section shape economic and reasonable, good mechanical properties, rolling point on the cross section of the extension of uniform, small internal stress, compared with ordinary I steel, has the advantages of large section modulus, light weight, save metal, can reduce the building structure 30-40%; And because its legs are parallel inside and outside, the leg end is a right Angle, assembling and combining components, can save welding, riveting work up to 25%. It is often used for large buildings (such as factories, high-rise buildings, etc.) requiring large bearing capacity and good cross-section stability, as well as Bridges, ships, lifting and transportation machinery, equipment foundation, supports, foundation piles, etc. Advantage: 1.High structural strength 2.The design style is flexible and rich 3.Light weight of structure 4. High structural stability, high degree of industrial production 5.Save labor and materials, convenient for mechanical processing,etc
Want to know more details of the product!
H beams are divided into hot rolled H beams and welded H beams, and hot rolled H beams are divided into wide flange H beams (HW), middle flange H beams (HM) and narrow flange H beams (HN). HW is h-shaped steel height and flange width are basically equal; It is mainly used for steel core column in reinforced concrete frame structure column, also known as stiffened steel column; It is mainly used for column in steel structure HM is h-shaped steel with a height and flange width ratio of 1.33~ 1.75, which is mainly used in steel structure: steel frame column is used as frame beam in frame structure under dynamic load; For example, device platform HN is h-shaped steel height and flange width ratio is greater than or equal to 2, mainly used for beam; The use of I-steel is equivalent to HN steel;
Application
H beam is mainly used in industrial and civil structure beam and column members. 1. Steel structure support for industrial structures 2. Steel pile and supporting structure of underground engineering 3. Petrochemical, power and other industrial equipment structure 4.Long span steel bridge members 5.Shipbuilding, machinery manufacturing frame structure 6.Girder support for trains, cars and tractors 7. Port conveyor belt, high-speed baffle support
Packaging&Shipping
In bulk or container,Standard seaworthy packing or as your required
More variety of products!
Company Profile
Shandong Zhongsheng Materials Co., Ltd. is a comprehensive, modern and high-quality enterprise integrating steel production, processing and sales. Located in the north near the port city: Jinan. Nearby Tianjin, Qingdao, Shanghai ports, low transportation cost, steel price concessions. Since its establishment, the company has developed rapidly. It has established long-term and stable cooperative relations with Shandong Iron and steel, Rizhao Iron and steel, Shanxi Taiyuan Iron and steel, Shanghai Baosteel, Xiwang special steel and other domestic steel mills. Main products: carbon steel, stainless steel, galvanized series, PPGI/PPGL series, aluminum series, copper series, steel pipe, section steel, rebar, steel wire, flange cutting parts, etc. Which are widely used in automobile, oil, railway, bridge,construction, electric power, transportation, machinery, shipbuilding, light industry, home appliances, kitchen and other important fields.
Shandong Zhongsheng Materials Co., Ltd. has become the most potential steel supply company in Shandong province in a short period of time. The company is supported by a strong capital chain and can accept LC, copy of bill of lading and other payment methods,which have been widely recognized by foreign customers. Our products not only sell well in the domestic market, but also sell well in the United States, Europe, Pakistan, South Korea, Japan, South Africa, Vietnam, Myanmar, Ethiopia, Australia, Bahrain,Singapore, Brazil, Russia and other countries and regions, and are highly praised by foreign customers. The number of export countries is growing, and the sales volume is gradually increasing.
Looking forward to doing business and making friends with clients all around the world!
Shandong Zhongsheng Materials Co., Ltd. has become the most potential steel supply company in Shandong province in a short period of time. The company is supported by a strong capital chain and can accept LC, copy of bill of lading and other payment methods,which have been widely recognized by foreign customers. Our products not only sell well in the domestic market, but also sell well in the United States, Europe, Pakistan, South Korea, Japan, South Africa, Vietnam, Myanmar, Ethiopia, Australia, Bahrain,Singapore, Brazil, Russia and other countries and regions, and are highly praised by foreign customers. The number of export countries is growing, and the sales volume is gradually increasing.
Looking forward to doing business and making friends with clients all around the world!
Customer Photos
Customer feedback
Certifications
FAQ
Q: Are you trading company or manufacturer ?
A: We are professional manufacturer for steel pipe/sheet/coil, and our company also is a very professional a trade company for steel products.we can also provide a wide range of steel products.
Q: Will you delivery the goods on time?
A: Yes,we promise to provide best quality products and delivery on time .Honesty is our company's tenet.
Q: Do you provide samples ? is it free or extra ?
A: The sample could can provide for customer with free,but the courier freight will be covered by customer account.
Q: Do you accept the third party inspection?
A: Yes absolutely we accept.
Q: How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by Linxu piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
Q: How do we trust your company?
A: We specialise in steel business for years, headquarter locates in Jinan, Shandong province, you are welcome to investigate in
any ways, by all means, you could place an order in with trade assurance which could secure your payment.
Q: How can I get your quotation as soon as possible?
A: The email and fax will be checked within 24 hours,meanwhile,the Skype,Wechat and WhatsApp will be online in 24 hours.Please send us your requirement and order information,specification(Steel grade,size,quantity,destination port),we will work out a best price soon.
A: We are professional manufacturer for steel pipe/sheet/coil, and our company also is a very professional a trade company for steel products.we can also provide a wide range of steel products.
Q: Will you delivery the goods on time?
A: Yes,we promise to provide best quality products and delivery on time .Honesty is our company's tenet.
Q: Do you provide samples ? is it free or extra ?
A: The sample could can provide for customer with free,but the courier freight will be covered by customer account.
Q: Do you accept the third party inspection?
A: Yes absolutely we accept.
Q: How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by Linxu piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
Q: How do we trust your company?
A: We specialise in steel business for years, headquarter locates in Jinan, Shandong province, you are welcome to investigate in
any ways, by all means, you could place an order in with trade assurance which could secure your payment.
Q: How can I get your quotation as soon as possible?
A: The email and fax will be checked within 24 hours,meanwhile,the Skype,Wechat and WhatsApp will be online in 24 hours.Please send us your requirement and order information,specification(Steel grade,size,quantity,destination port),we will work out a best price soon.
Want to Know more details about this product
