RAL9016 PPGI Coil 2ft 4ft Galvanized Steel Coil Metal Per Ton for White Surface More Colors Customer Sheet
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | Zhongsheng |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Ton |
|---|---|
| Price: | $600.00/tons 1-24 tons |
|
Detail Information |
|||
| Application: | Making Pipes, Cutting Sheets, Making Small Tools, Making Corrugated Sheets, Making Container, Making Fences | Type: | Steel Coil |
|---|---|---|---|
| Thickness: | 0.12-3.0mm | Standard: | ASTM |
| Width: | 100-1250mm | Length: | Coil |
| Certificate: | API, Ce, Rohs, SNI, BIS, SASO, PVOC, SONCAP, SABS, Sirm, Tisi, KS, JIS, GS, ISO9001 | Grade: | DX51D+Z/SGCC/DC01+Z/DC51D+Z Etc |
| Coating: | Z121-Z180 | Tolerance: | ±1% |
| Processing Service: | Welding, Punching, Cutting, Bending, Decoiling | RAL Color: | Red, Blue, Green, White, Grey, Ects. |
| Hardness: | Full Hard, Medium Hard(HRB60-85) | Delivery Time: | Within 7 Days |
| Product Name: | PPGL Coil | Surface: | PE Coated |
| Color: | Red, Blue, Green, White, Grey, Ects. | Keyword: | PPGI Coil Prepainted Steel Coil |
| Shape: | Coil Roll | Material: | ASTM/AISI/SGCC/CGCC/TDC51DZM/TDC52DTS350GD/TS550GD/DX51D+Z Q195-q345 |
| Packages: | Standard Package | Coil Weight: | 3-8 Tons |
| MOQ: | 1 Tons | ||
Product Description
Product Description
HIGH PERFORMANCE
Excellent corrosion resistance 8 high heat resistance & adequate zinc layer
HIGH QUALITY
Best raw materials for production advanced technologiesand thorough inspection system
CUSTOMIZABLE SURFACE
perfect painting& beautiful appearance customize your different needs
PPGI/PPGL | ||
Standard | JIS G3302, JIS G3313 | |
ASTM A653 | ||
GB/T2518-88, GB11253-9, BS, etc. | ||
BASE MATERIAL | HDGI HDGL | |
Thickness | 0.12-3.0mm | |
Width | 100mm-1250mm or as you require | |
Zinc Coating | Z20-Z275,AZ30-AZ150 | |
Painting Thickness | Top side: 10-20microns | |
Primer: 5~7microns | ||
Back side: 5~7microns | ||
Color | RAL Color | |
Package weight | 2 -6 ton per coil | |
Inner Diameter | 508mm, 610mm | |
Surface Production | PE, PVDF, SMP, HDP etc | |
Packing | Each bare coil to be securely tied with two bands through the eye of coil (or not) and one circumferential. | |
The contact points of these bands on the coil edge to be protect with edge protectors. | ||
Coil to be properly wrapped with water proof /resistant paper, it then to be properly and completely metal wrapped. | ||
Coating Type
Polyester (PE): Good adhesion, rich colors, wide range in formability and outdoor durability, medium chemical resistance, and low cost.
Silicon modified polyester(SMP): Good abrasion resistance and heat resistance, as well as good external durability and chalking resistance, gloss retention, general flexibility, and medium cost.
High Durability Polyester(HDP): Excellent color retention and anti-ultraviolet performance, excellent outdoor durability and anti-pulverization, good paint film adhesion, rich color, excellent cost performance.
Polyvinylidene Fluoride(PVDF): Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, excellent solvent resistance, good moldability, stain resistance, limited color, and high cost.
Polyester (PE): Good adhesion, rich colors, wide range in formability and outdoor durability, medium chemical resistance, and low cost.
Silicon modified polyester(SMP): Good abrasion resistance and heat resistance, as well as good external durability and chalking resistance, gloss retention, general flexibility, and medium cost.
High Durability Polyester(HDP): Excellent color retention and anti-ultraviolet performance, excellent outdoor durability and anti-pulverization, good paint film adhesion, rich color, excellent cost performance.
Polyvinylidene Fluoride(PVDF): Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, excellent solvent resistance, good moldability, stain resistance, limited color, and high cost.
Packing & Delivery
Exported sea worthy packing: 3 layers of packing. Inside is craft paper, middle is waterproof plastic film and outside GI steel sheet to be covered by steel strips with lock.
